AU-11SA-4K22 HDMI Audio De-embedder (up to 7.1) with built-in Repeater (4K, HDCP2.2, HDMI2.0)
- The CYP OR-42-4K22 4x2 HDMI Matrix Switcher is designed to enable the user to switch between any of the four connected HDMI sources to send video and audio to any of the four connected HDMI display. This matrix switcher fully supports 4K resolutions and is HDMI2.0 and HDCP 2.2 compliant, ensuring maximum compatibility with the latest 4K UHD sources and displays.
- CYP 4K bring the company out of the past and into the future by providing 4k solutions to every audio visual environment.
The AU-11SA-4K22 advanced digital audio decoder is designed to de-embed 2-channel or multi-channel audio from the connected HDMI input and breakout this audio to provide 7.1 analogue audio connections, plus a 5.1 optical audio output and a HDMI bypass output. This device supports bypass of high resolution digital audio formats including LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and DTS-HD Master Audio, and supports audio sampling rates up to 192kHz.
CYP Europe has the simple vision of delivering market leading connectivity solutions that enhance the capabilities of Audio Visual products in any installation environment. Continued dedication and focus has established CYP Europe a market leader in the Pro AV Industry throughout Europe. 4K UHD Video Wall Plug and Play Simplicity From CYP. Page 1 EL-41S-4K 4-Way HDMI Switcher with advanced EDID management, IP, RS-232, & IR Control (4K resolution support) OPERATION MANUAL.; Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. CYP (UK) Ltd assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. CYP - Real 4K@60 seamless matrix with PIP/POP - CPLUS-V4H2HPIP.
In addition, the AU-11SA-4K22 supports 4K video resolutions, HDMI 2.0, and HDCP 2.2 ensuring stunning results and maximum compatibility for any AV system.
Delivery policy
Description
- HDMI 2.0, HDCP 2.2 and DVI compliant
- HDMI audio decoder with built in repeater
- Supports HDTV resolutions up to 4Kx2K (3840x2160@24/25/30/ 50/60 YUV_444 & 4096x2160@24/25/30/50/60 YUV_444)
- The optical output supported audio : LPCM, Dolby Digital and DTS up to 5.1
- HDMI Bypass output supported audio : Dolby True HD, Dolby Digital Plus, and DTS-HD Master Audio
- Analogue stereo audio outputs support LPCM 2 channel, 5.1 and 7.1
- Audio sampling rate up to 192 kHz
- HDMI supports high-bit-rate (HBR) audio
- Features CEC bypass function
| Inputs | 1x HDMI [1x HDMI 2.0 Uncompressed AV and Data] |
| Outputs | 1x HDMI [1x HDMI 2.0 Uncompressed AV and Data] 1x Toslink [1x Optical Dolby Digital / DTS / 2 Channel LPCM] 1x RCA [1x Front Left Mono] 1x RCA [1x Front Right Mono] 1x RCA [1x Front Centre Mono] 1x RCA [1x Low Frequency Effect Mono] 1x RCA [1x Right Rear Mono] 1x RCA [1x Rear Left Mono] 1x RCA [1x Rear Right Centre Mono] 1x RCA [1x Rear Left Centre Mono] |
| PSU: | 5V/2.6A |
| Dimensions | 118mm [W] x 231mm [D] x 25mm [H] |
| Net Weight | 620g |
| Gross Weight | 818g |
